IL-Z-2PL-SMTYE
| Manufacturer | |
| Description | ヘッダ & ワイヤハウジング 2P Pin Header 1.25mm R/A SMT CONN HDR 1.25MM 2POS SMD R/A TIN Headers & Wire Housings 2P Pin Header 1.25mm R/A SMT PCBTOCABLE(PINHEADER)-SINGLEROWCRIMPSTYLE,1.25MMPITCH,2CONTACTS |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Headers & Wire Housings | Standard Package | 500 |
| Factory Pack Quantity | 1000 | ||
Compliance
| RoHS | RoHS Compliant | Material Flammability Rating | UL94V-0 |
Electrical
| Voltage Rating | 500 V | Current Rating (Max) | 1 A |
Mechanical
| Color | Brown | Pitch | 0.049" (1.25mm) |
| Packaging | Tray | Cable Exit | LowProfile |
| Wire Gauge | 30-28 | Termination | Solder |
| Contact Type | Male Pin | Length - Pin | 0.5mm |
| Mounting Type | Surface Mount, Right Angle | Angle of Throw | Right |
| Connector Type | Header, Shrouded | Contact Finish | Tin |
| Number of Rows | 1 | Contact Material | Brass |
| Housing Material | PPS | Length - Overall | 7.65mm |
| Primary Material | PCBtoCable | Pin Hole Diameter | 1.25mm |
| Termination Style | SMD | 1st Contact Gender | Pin (Male) |
| Number of Contacts | 2 | Number of Positions | 2 |
| Contact Length - Mating | 0.108" (2.75mm) | ||
Product Info
| Type | Shrouded | Series | IL-Z |
| Features | Pinstrip | Manufacturer | IL-ZSeries |
| Product Type | Headers | Number of Positions Loaded | All |
Environmental
| Operating Temperature | -40to+85°C | ||
