FI-W31S
| Manufacturer | |
| Description | FFC & FPC Connectors 1.25MM PCB-FLEX/WIRE CONN PLUG 1.25MM 31POS CBL MNT PCBTOCABLEPLUG-LCDCOMPATIBLE,1.25MMPITCH,31CONTACTS 31 WAY HOUSING |
| Category |
Business
| Product Category | FFC & FPC Connectors | Standard Package | 283 |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | RoHS Compliant | Automotive | NO |
| Leadfree Defin | RoHS-conform | Material Flammability Rating | UL94V-0 |
Electrical
| Current Rating (Max) | 1 A | ||
Mechanical
| Color | Black | Pitch | 0.049" (1.25mm) |
| Packaging | Tray | Cable Exit | LowProfile |
| Termination | Screw | Contact Type | Female Socket |
| Pitch - Post | FEMALE | Mounting Type | Free Hanging (In-Line) |
| Angle of Throw | Straight | Connector Type | Plug |
| Number of Rows | 2 | Housing Material | Nylon |
| Length - Overall | 22.25mm | Primary Material | BoardtoCable |
| Pin Hole Diameter | 1.25mm | Termination Style | SMD |
| Number of Contacts | 31 | Contact Termination | Crimp |
| Number of Positions | 31 | ||
Product Info
| Note | Contacts Not Provided | Type | CablePlug |
| Series | FI | Features | LCDCompatible,Shielded |
| Manufacturer | FISeries | Product Type | Free Hanging |
Environmental
| Operating Temperature | -40to+80°C | ||
Documents & Media
Similar Parts
FI-W31P-HFE-E1500
JAE Electronics
FFC & FPC Connectors 31p Recep RA SMT LCD Compatible CONN RCPT 1.25MM 31POS SMD R/A
FI-W31P-HFE
JAE Electronics
FFC & FPC Connectors 1.25MM 31P RECEPT RT ANGLE CONN RCPT 1.25MM 31POS SMD R/A PCBTOCABLERECPETACLE-LCDCOMPATIBLE,1.25MMPITCH,31CONTACTS 31P FEMALE HEADER SMT 1,25MM
FI-TWE31PB-VF-E1400
JAE Electronics
FFC & FPC Connectors 31p SMT Recept board side solder CONN RCPT 1.25MM 31POS SMD GOLD 31P FEMALE HEADER 1,25MM 2R
FI-C3-A1-15000
JAE Electronics
FFC & FPC Connectors Cable Side Contact FI Series Crimp CONN SOCKET CRIMP 28-32AWG GOLD Contact;CableSide;PCBtoCable;FISeries;GoldoverNickel PCBtoCable-CableSideContacts(Stripof1000) PCBtoCable-FISeriesCableSideContact(SoldinReelof15,000) FEMALE CRIMP CONTACTS AWG 28-32
FI-WE31P-HFE
