CA3100ER20-27P
| Manufacturer | |
| Description | Conn MIL-C-5015 Circular PIN 14 POS Solder ST Wall Mount 14 Terminal 1 Port CONN RCPT 14POS WALL MNT W/PINS CIRCULAR, SIZE 20, 14WAYS, PIN |
| Category |
Business
| Other Names | CA3100ER2027P | Standard Package | Bulk |
Compliance
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | Approval Agency | :MIL-C-5015 |
Electrical
| Voltage Rating | 500VAC, 700VDC | ||
Mechanical
| Weight | 0.01 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Solder |
| Weight (g): | 50.22600 | Mounting Type | Wall Mount |
| Connector Type | Receptacle, Male Pins | Contact Finish | Silver |
| Fastening Type | Threaded | Insertion Angle | :20-27 |
| Material - Body | :Aluminium | Contact Material | :Copper |
| 1st Contact Gender | :Pin | Number of Contacts | :14 |
| Contact Termination | :Crimp | Number of Positions | 14 |
| Shell Size - Insert | 20-27 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| 1st Connector Mounting Type | :Wall | ||
Product Info
| Type | MIL-C-5015 Circular | Gender | RCP |
| Series | :CA-Threaded | ||
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
