CA3106E20-27SF80
| Manufacturer | |
| Description | CONN PLUG 14POS INLINE W/SKTS CIRCULAR, SIZE 20, 14 WAY SKT |
| Category |
Business
| Standard Package | 1 | ||
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85369010 |
| Approval Agency | :MIL-C-5015 | ||
Electrical
| Voltage Rating | 500VAC, 700VDC | ||
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Crimp |
| Weight (g): | 107.40000 | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug, Female Sockets | Contact Finish | Silver |
| Fastening Type | Threaded | Insertion Angle | :20-27 |
| Material - Body | :Aluminium | Contact Material | :Copper |
| 1st Contact Gender | :Socket | Number of Contacts | :14 |
| Contact Termination | :Crimp | Number of Positions | 14 |
| Shell Size - Insert | 20-27 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| 1st Connector Mounting Type | :Cable | ||
Product Info
| Gender | :Socket | Series | :CA-Threaded |
| Features | Strain Relief | ||
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
