KPSE06E16-26SF0

Manufacturer	ITT Inc.
Description	CONN HSG CABLE MNT PLUG 26POS CIRCULAR, SIZE 16, 26 WAY SKT
Category	Connector SolutionsCircular ConnectorsMilitary Circular Connectors

对参数有疑问？问 AI 助手

Business

Standard Package

Compliance

SVHC	:No SVHC (20-Jun-2013)	Tariff No	85369010
Approval Agency	:MIL-C-26482

Mechanical

Weight	0.001	Packaging	Bulk
Orientation	N (Normal)	Weight (g):	32.00000
Contact Size	20	Contact Type	Crimp
Mounting Type	Free Hanging (In-Line)	Connector Type	Plug for Female Contacts
Fastening Type	Bayonet Lock	Insertion Angle	:16-26
Material - Body	:Aluminium	1st Contact Gender	:Socket
Number of Positions	26	Shell Size - Insert	16-26
Shell Material, Finish	Aluminum, Olive Drab Cadmium Plated	1st Connector Mounting Type	:Cable

Product Info

Note	Contacts Not Provided	Gender	:Socket
Series	:KPSE

Environmental

Ingress Protection

Environment Resistant

Documents & Media

Online Document

KPT/KPSE Connectors Catalog

PDF Document

KPSE06E16-26SF0 Drawing

PDF Document

58286.pdf
