KPSE02E16-26PF0

Manufacturer	ITT Inc.
Description	CONN HSG BOX MNT RCPT 26POS CIRCULAR, SIZE 16, 26 WAY PIN
Category	Connector SolutionsCircular ConnectorsMilitary Circular Connectors

对参数有疑问？问 AI 助手

Business

Standard Package

Compliance

SVHC	:No SVHC (20-Jun-2013)	Tariff No	85369010
Approval Agency	:MIL-C-26482

Mechanical

Weight	0.001	Packaging	Bulk
Orientation	N (Normal)	Weight (g):	15.20000
Contact Size	20	Contact Type	Crimp
Mounting Type	Panel Mount, Flange	Connector Type	Receptacle for Male Contacts
Fastening Type	Bayonet Lock	Insertion Angle	:16-26
Material - Body	:Aluminium	1st Contact Gender	:Pin
Number of Positions	26	Shell Size - Insert	16-26
Shell Material, Finish	Aluminum, Olive Drab Cadmium Plated	1st Connector Mounting Type	:Panel

Product Info

Note	Contacts Not Provided	Gender	:Plug
Series	:KPSE

Environmental

Ingress Protection

Environment Resistant

Documents & Media

PDF Document

KPSE02E16-26PF0 Drawing

Online Document

KPT/KPSE Connectors Catalog

PDF Document

58286.pdf
