SP232ACT-L
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | RS-232 Interface IC | Standard Package | 41 |
| Factory Pack Quantity | 41 | Standard Package Name | SOIC W |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423190 | Part Status | :232 |
Electrical
| Data Rate | 240Kbps | Interface | EIA/TIA-232|ITU-T V.28 |
| Input Signal | Single-Ended | Signal Types | Single-Ended |
| Data Rate (Max) | Point-to-Point | Current - Output | 5 mA |
| Current - Supply | 5 | Driver Circuitry | :RS-232 |
| Voltage - Supply | 4.5 V ~ 5.5 V | Power Supply Type | Single |
| Receiver Hysteresis | 500mV | Power Dissipation (Max) | :375mW |
| Delay Time - Propagation | 1.5 us | Current - Off State (Max) | :1µA |
| Voltage - Supply (Vcc/Vdd) | :6V | Number of Receivers per Line | 2 (RS232) |
| Current - Average Rectified (Io) | :3mA | Common Mode Transient Immunity (Min) | Commercial |
Mechanical
| Width | 7.5mm | Height | 2.55mm |
| Length | 10.3mm | Weight | 0.0008 |
| Packaging | Tube | Case Color | :SOIC |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :16 |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | Package Cooled | SOICW |
| Material Finish | :MSL 3 - 168 hours | Package Quantity | SOIC W |
| Size / Dimension | 10.3 x 7.5 x 2.55mm | Number of Positions | 16 |
| Supplier Device Package | 16-SOIC W | ||
Product Info
| Spg | 47 | Type | Transceiver |
| Duplex | Full | Function | Line Transmitter/Receiver |
| Protocol | RS232 | Shutdown | No |
| Base Unit | :232 | Number of Units | 1 |
| Number of Drivers | 2 | Number of Receivers | 2 |
| Number of Transmitters | 2 | Number of Inputs and Type | 8 |
| Number of Drivers/Receivers | 2/2 | Number of Transmitters/Receivers | 1 |
Environmental
| Temperature Range | :Commercial | Operating Temperature | 0°C ~ 70°C |
Documents & Media
PDF Document
Online Document
PDF Document
PDF Document
PDF Document
.jpg&w=3840&q=75)
.jpg&w=3840&q=75)
Sourcing & traceability
- Datasheet
- Multiple Changes 26/Jul/2013
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
