516-056-000-302
| Manufacturer | |
| Description | CONN RACK & PANEL PLUG 56POS Standard EDAC516 56 way panel plug,8.5A Rack & Panel Connectors 56P PLUG WITH NUT Conn Rack and Panel PL 56 POS Crimp ST Panel Mount PLUG, WITH LOCK NUT, 56 WAY RACK & PANEL CONNECTOR, PLUG, 56POS Plug; Connector: rectangular; 516; hermaphrodite; PIN:56; 2kV Panel plug housing Pitch3.81 mm / 6.6 mm Poles 56 for panel mount / For hermaphroditic contacts 516, 516-056-000-302, Edac |
| Category |
Business
| Other Names | 151-1033 | Product Category | Rack & Panel Connectors |
| Standard Package | 25 | ||
Compliance
| RoHS | Not Applicable | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85366990 | ||
Electrical
| AC Voltage - Input | 2kV | Current Rating (Max) | 8.5A |
| Connector - Voltage Input | with threaded hole | ||
Mechanical
| Color | Gray | Depth | 80.95mm |
| Pitch | 0.150" (3.81mm) | Width | 22.25mm |
| Length | 65.84mm | Weight | 0.018 |
| Packaging | Bulk | Body Material | polycarbonate |
| Mounting Type | Varies by Contact | Connector Type | Housing for Non Gendered Contacts |
| Contact Finish | Gold | Number of Rows | 9 |
| Connector Style | Rack and Panel | Connector Usage | Plug |
| Contact Material | Phosphor Bronze | Housing Material | Polycarbonate (PC) |
| Package Quantity | 25 | Size / Dimension | 65.84 x 22.25 x 80.95mm |
| Connector - Cable | plug | Termination Style | Screw |
| 1st Contact Gender | :Pin | Number of Contacts | 56 |
| Contact Termination | :- | Number of Positions | 56 |
| Shell Size - Insert | :- | 1st Connector Mounting Type | :Cable |
Product Info
| Spg | 25 | Note | Contacts Not Provided |
| Gender | Male | Series | EDAC516 |
| Features | Jackscrew Socket, Mating Guide | Product Type | Plug Connectors |
| Adapter Series | 516 | Number of Units | 1 |
Environmental
| Operating Temperature | +105°C | ||
