DB3CB1LB
| Manufacturer | |
| Description | Switch Snap Action N.O./N.C. SPDT Short Straight Lever Quick Connect 0.1A 250VAC 80VDC 0.59N Screw Mount SW SNAP SPDT 0.1A QC TERM 125V |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | CH880 | Standard Package | 1,120 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SPDT | Voltage Rating | 125V |
| Switch Function | On-Mom | Voltage - Rated AC | 250V VAC |
| Differential Travel | 0.020" (0.5mm) | Current Rating (Max) | 100mA (AC) |
| Voltage - Input (Min) | 250 | Switch Function/Rating | N.O./N.C. |
| Voltage - DC Spark Over (Nom) | 250V VDC | ||
Mechanical
| Depth | 6.5 mm | Height | 23.65 mm |
| Packaging | Bulk | Pretravel | 0.157" (4.0mm) |
| Overtravel | 0.079" (2.0mm) | Actuator Type | Lever, Straight |
| Mounting Type | Screw Mount | Terminal Type | Quick Connect |
| Mounting Style | Screw | Operating Force | 60gf |
| Contact Material | Gold Silver Platinum|Silver Nickel | Length - Overall | 20 mm |
| Actuator Material | Stainless Steel/Polybutylene Tere... | Termination Style | Quick Connect - 0.110" (2.8mm) |
| Actuator Style/Size | Short Straight Lever | Switch Actuation Level | SPDT |
| Material - Housing & Prism | Polyethylene Terephthalate/N/A | ||
Product Info
| Electrical Life | 100,000 Cycles | Operating Position | 0.420" (10.7mm) |
Environmental
| Mechanical Life | 15,000,000 Cycles | Ingress Protection | IP50 - Dust Protected |
| Operating Temperature | -40°C ~ 120°C | Operating Temperature - Junction | 120C |
