AD7790BRMZ
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 50 |
| Standard Package Name | MSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Rad Hardened | No | ||
Electrical
| Interface | Serial (3-Wire, SPI, QSPI, Microwire) | Input Type | Voltage |
| Resolution | 16 Bit | Input Signal | Differential |
| INL/DNL (LSB) | ±15ppm of FSR | Power - Input | Single |
| Power - Rated | 0.225 W | Converter Type | Temperature Measurement |
| Data Interface | DSP, MICROWIRE™, QSPI™, Serial, SPI™ | Input Polarity | Bipolar |
| Number of Bits | 16 | Voltage Rating | ±2.5V |
| Data Rate (Max) | 120 SPs | Voltage - Rated | �2.5 |
| Current - Output | :145µA | Voltage - Supply | 3.3 V, 5 V |
| Resolution (Bits) | :16bit | Voltage Reference | External |
| Number of Channels | 1 Channel | Number of Elements | 1 |
| Sampling Frequency | 120 sps | Number of ADCs / DACs | 1 |
| Voltage Supply Source | Single | Power Dissipation (Max) | 800 uW |
| Voltage Supply - Internal | :2.5V to 5.25V | Sampling Rate (Per Second) | 120 |
| Differential - Input:Output | Yes | Voltage - Supply Span (Typ) | Not Required V |
Mechanical
| Width | 3mm | Height | 0.85mm |
| Length | 3mm | Weight | 0.0001 |
| Packaging | Tube | Lead Style | Gull-wing |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :10 |
| Package / Case | 10MSOP | Package Cooled | MSOP |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 3 |
| Package Quantity | MSOP | Size / Dimension | 3 x 3 x 0.85mm |
| Number of Positions | 10 | Shell Size - Insert | 0.85 |
| Supplier Device Package | 10-MSOP | ||
Product Info
| Series | AD7790 | Base Unit | :7790 |
| Architecture | Delta-Sigma | Printed Circuit Board | 10 |
| Number of A/D Converters | 1 | Number of Inputs and Type | 1 Differential, Bipolar |
Environmental
| Operating Temperature | -40°C ~ 105°C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- AD7790.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
