LT3756EUD#PBF

Manufacturer	Analog Devices, Inc.
Description	LED DRVR 18Segment 9V/12V/15V/18V/24V 16-Pin QFN EP IC LED DRVR HP CONST CURR 16-QFN LT3756EUD#PBF, LCD Display Driver 18-Segments, 6 to 100V, 16-Pin QFN16EP 18段 LED 驱动器, 6 → 100 V, 16引脚 QFN封装
Category	Integrated CircuitsPower Management ICsLED Lighting Drivers

对参数有疑问？问 AI 助手

Business

Other Names	LT3756EUDPBF	Standard Package	121
Standard Package Name	QFN

Compliance

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Rad Hardened	No

Electrical

Frequency	100kHz ~ 1MHz	Voltage Rating	6 → 100 V
Current - Supply	0.005 mA	Voltage - Supply	6 V ~ 100 V
Number of Outputs	1	Current Rating (Max)	0.005 mA
Voltage - Input (Min)	100V	Voltage - Supply (Min)	6 V
Constant Current Load - Max	Yes	Common Mode Transient Immunity (Min)	Extended

Mechanical

Width	3mm	Height	0.7mm
Length	3mm	Packaging	Tube
Lead Style	No Lead	Mounting Type	Surface Mount
Number of Pins	16	Package / Case	16-WFQFN Exposed Pad
Package Cooled	QFN16EP	Package Quantity	QFN EP
Size / Dimension	3 x 3 x 0.7mm	Number of Positions	16
Supplier Device Package	16-QFN-EP (3x3)

Product Info

Type	White LED	Function	Y
Topology	Flyback, Low Side, PWM, SEPIC, Step-Down (Buck), Step-Up (Boost)	Number of Segments	18
Internal Connection	No

Environmental

Operating Temperature

-40°C ~ 125°C

Operating Temperature - Junction

125C
