191-2801-140
| Manufacturer | |
| Description | Flat Cables 28 AWG Ribbon .050 Zip 40 Cond FLAT CABLE 40PTS AWG28 Planar/ribbon cable,1.27mm pitch,40 way cable;flat(planar);gray pvc insul w/1 red edge;40 conductors;28 awg stranded; 30m Flat Cable 40Conductors 28AWG 30.48m Tinned Copper Gray/Red Edge 300V 1A RIBBON CABLE, 40WAY, PER M FLAT CABLE, 40COND, 100FT, 28AWG, 300V RIBBON CABLE, 40WAY, 30.5M cable, flat(planar), gray pvc insul w/1 red edge, 40 conductors, 28 awg stranded Cable: ribbon; 1.27mm; stranded; Cu; 40x28AWG; PVC; grey; 30,5m Ribbon Cable 1.27 mm 40xAWG 28, 191-2801-140, Amphenol Amphenol Spectra-Strip 系列 40 路 无屏蔽 带状电缆, 50.8 mm 宽 |
| Category |
Business
| MOQ | 1 | Product | Ribbon Cable |
| Unit Pack | 1 | Part # Aliases | 608-7140 78K6419 |
| Product Category | Flat Cables | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Standards | UL, CSA AWM I A, FT-1 | Tariff No | 85444995 |
| Automotive | NO | Leadfree Defin | RoHS-conform |
| Approval Agency | :CSA, UL | ||
Electrical
| Core Type | 7/36 | Impedance | 105 Ω |
| Isolation | GREY | Inductance | :0.59µH/m |
| Capacitance | 45.92 pF/m | Voltage Rating | 300 V |
| Conductor Strand | Stranded | Current Rating (Max) | 1 A |
| Number of Conductors | 40 | Insulation Resistance | :10000Mohm |
Mechanical
| Color | Gray | Pitch | 1.27 mm |
| Width | 50.8 mm | Length | 100 ft |
| Weight | 0.085 | Boreholes | 49.53mm |
| Packaging | Spool | Shielding | Unshielded |
| Wire Type | ribbon | Cable Type | Ribbon Cable, Planar |
| Wire Gauge | 28 | Shield Type | Unscreened |
| Cable Length | 30m | Jacket Color | :Grey |
| Pitch - Post | 105mm | Core Diameter | 28AWG |
| Cable Diameter | ULmm | Cable Material | no flame propagation |
| Card Thickness | 300mm | Insulation Color | grey |
| Length - Overall | 191mm | Size / Dimension | see |
| Packages Included | 30,5m | Color - Connectors | Grey |
| Conductor Material | Tinned Copper | Number of Contacts | 40 |
| Insulation Material | Polyvinyl Chloride (PVC) | Material - Insulation | Polyvinylchloride |
| Number of Cable Pairs | 7 x 36 | Number of Cores/Bus Width | 7 |
| Wire Gauge or Range - AWG | 36 AWG | Number of Positions/Bay/Row | 40 |
| Jacket (Insulation) Material | Polyvinyl Chloride (PVC) | UL Insulation System Approval | :UL2651 |
Product Info
| Matchcode | 1912801140 | Number of Cores | 40 |
| Number of Units | 1 | Standard Leadtime | 8 weeks |
| Application Specifics | For general-purpose interconnection in electronic products from calculators and automobiles to computers and switching networks | ||
Environmental
| Temperature Rating | +105 °C | Operating Temperature | :105°C |
