SJS830250
| Manufacturer | |
| Description | Lighting Connectors Luminus Size 22 2P Inline Plug CONN HSG PLUG 2POS INLINE SKT 2 Pole Male MIL Spec Circular Connector, Shell Size 5 with Male Contacts SJS Series, Twist Lock QRATE Amphenol SJS 系列 2路 连接器 插头 , 公触点, 扭锁接合 |
| Category |
Business
| Product | Housings | Tradename | Luminus |
| Other Names | APC1627 | Product Category | Lighting Connectors |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Voltage Rating | 600 V | Current Rating (Max) | 5A |
Mechanical
| Outline | 5 | Packaging | Bulk |
| Shell Size | 5 | Wire Gauge | 22 |
| Weight (g): | 1.00000 | Contact Size | 22D |
| Contact Type | Crimp | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug for Female Contacts | Fastening Type | Bayonet Lock |
| Mounting Style | Self Locking | Connector Usage | Twist Lock |
| Contact Material | Stainless Steel | Housing Material | Polyamide (PA) |
| Termination Style | Quick Connect | 1st Contact Gender | Male |
| Number of Contacts | 2 | Number of Positions | 2 |
| Shell Size - Insert | 5 | Shell Material, Finish | Polyamide (PA66), Nylon 6/6 |
Product Info
| Note | Contacts Not Provided | Type | Circular Twist & Lock |
| Gender | Male | Series | SJS |
Environmental
| Ingress Protection | Environment Sealed | Operating Temperature | +125°C |
