点击放大查看
SJS512210
| Manufacturer | |
| Description | SJS QUICK DISCONNECT SPLICE Lighting Connectors 1 POS SIZE 12 RECP. RED RECEPTACLE, SIZE 12, RED, 1 WAY CONN HSG RCPT 1POS INLINE PIN |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Housings | Tradename | Luminus |
| Product Category | Lighting Connectors | Standard Package | 25 |
Compliance
| RoHS | No | Tariff No | 85366110 |
| Material Flammability Rating | UL94 V-0 | ||
Electrical
| Voltage Rating | 600 V | Current Rating (Max) | 23 A |
Mechanical
| Color | Red | Length | 1.12 in |
| Weight | 0.002 | Packaging | Bulk |
| Contact Size | 12 | Contact Type | Crimp |
| Mounting Type | Free Hanging (In-Line) | Connector Type | :Circular Military |
| Contact Finish | :- | Fastening Type | Push-Twist |
| Mounting Style | In-Line | Insertion Angle | :- |
| Material - Body | :Nylon 6.6 (Polyamide 6.6) | Contact Material | Stainless Steel |
| 1st Contact Gender | :Pin | Color - Connectors | :Red |
| Number of Contacts | :1 | Contact Termination | :Crimp |
| Number of Positions | 1 | Shell Size - Insert | :12 |
| Shell Material, Finish | Polyamide (PA66), Nylon 6/6 | 1st Connector Mounting Type | :Cable |
Product Info
| Note | Contacts Not Provided | Type | Receptacle |
| Gender | :Socket | Series | SJS |
| Application Specifics | Wire to Board | ||
Environmental
| Ingress Protection | Environment Sealed | ||
Documents & Media
PDF Document
PDF Document
