618009231221
| Manufacturer | |
| Description | 8.08mm 9w Header 90deg D-sub Connector D-Sub Standard Connectors WR-DSUB Male Angled PCB Connector 9p PLUG, D-SUB, PCB, R/A, 9WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 9 路 直角 通孔安装 PCB D-sub 连接器 插头 |
| Category |
对参数有疑问？问 AI 助手
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85366990 | ||
Electrical
| Range deg/s | :WURTH ELEKTRONIK - R/A PCB Mount Dsub | Voltage Rating | 125 V ac |
| Current Rating (Max) | 3A | ||
Mechanical
| Depth | 18.5mm | Pitch | 2.77 mm, 2.84 mm |
| Width | 12.5mm | Height | 12.5 mm |
| Length | 30.8mm | Weight | 0.00799 |
| Packaging | Tray | Insulation | Insulated |
| Shell Size | :DE | Contact Type | Stamped / Formed Contacts |
| Mounting Type | Right Angle | Shell Plating | Nickel |
| Contact Finish | Gold | Number of Rows | 2 |
| Shell Material | Steel | Contact Material | Copper Alloy |
| Housing Material | Steel | Size / Dimension | 30.8 x 12.5 x 18.5mm |
| Termination Style | SMD | Number of Contacts | 9 |
| Contact Termination | :Solder | Insulation Material | Polybutylene Terephthalate (PBT) |
Product Info
| Gender | Male | Series | 618 |
Environmental
| Mating Cycles | :50 | Operating Temperature | +85°C |
