744314650
| Manufacturer | |
| Description | 固定インダクタ WE-HCI Inductor 6.5uH 100kHz 6A INDUCTOR POWER 6.5UH 6.0A SMD Inductor SMD high current WE-HCI 6.5uH Fixed Inductors WE-HCI Inductor 6.5uH 100kHz 6A INDUCTOR, SMD, HIGH CURRENT 6.5UH Wurth WE-HCI 系列 屏蔽 WE-Superflux芯材 绕线贴片电感器, 6.5 μH ±20%, 6A Idc |
| Category |
Business
| Product | High Current Inductors | Other Names | 732-1162-2 |
| Standard Package | 1,000 | Factory Pack Quantity | 1000 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85045095 | ||
Electrical
| Core Type | :Shielded | Tolerance | ±20% |
| Inductance | 6.5µH | Range deg/s | :WURTH ELEKTRONIK - WE-HCI Series |
| Test Frequency | 100kHz | Inductance Range | :± 20% |
| DC Resistance (DCR) | 21.5 mOhm | Current Rating (Max) | 6A |
| DC Resistance (DCR) (Max) | :0.0215ohm | Frequency - Self Resonant | 50MHz |
| Current - Saturation (Isat) | :6A | Current Saturation - Series | 6A |
| Resistance - Initial (Ri) (Min) | 21.5mΩ | Current - On State (It (RMS)) (Max) | :6A |
Mechanical
| Depth | 6.9mm | Width | 6.9 mm |
| Height | 4.8mm | Length | 7mm |
| Weight | 0.0016 | Packaging | Tape & Reel (TR) |
| Shielding | Shielded | Shield Type | Yes |
| Core Material | WE-Superflux | Mounting Type | Surface Mount |
| Number of Pins | :2 | Package / Case | Non Standard |
| Size / Dimension | 0.272" L x 0.272" W (6.90mm x 6.90mm) | Termination Style | SMD/SMT |
| Dimensions - Overall | :7mm x 6.9mm x 4.8mm | Height - Seated (Max) | 0.197" (5.00mm) |
Product Info
| Type | Wirewound | Series | WE-HCI |
Environmental
| Operating Temperature | -40°C ~ 150°C | ||
Documents & Media
Similar Parts
XRP7708EVB
Exar
Power Management IC Development Tools Evaluation Board for XRP7708 Series Evaluation Board For Quad-Output Digital PWM Buck Controller Supporting High Current Loads EVAL BOARD FOR XRP7708 Development Kit, Power Management With Evaluation Board for XRP7708 EXAR
SP7656EN2-L
