744230450
| Manufacturer | |
| Description | Common Mode Filters / Chokes WE-CNSW Line Filter 45ohm 100MHz 650mA CHOKE COM MODE 45 OHM .65A SMD CNSW Data Line Filter 0603 45Ohm 650mA LINE FILTER, 0603, 45OHM, 0.65A Wurth Elektronik WE-CNSW 系列 0.65A 50 V 直流, 10 至 1000MHz SMD RFI 滤波器 , 带贴片接端 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Common Mode Inductors | Other Names | 732-2581-2 |
| Standard Package | 2,000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85045095 | ||
Electrical
| Current | 650mA | Frequency | 10 → 1000MHz |
| Impedance | 45 Ohm | Tolerance | 25 % |
| Resistance | :110mohm | Filter Type | Data, Signal Line |
| Test Frequency | 100 MHz | Voltage Rating | :50V |
| DC Resistance (DCR) | 110 mOhm Max | Current Rating (Max) | 650mA |
| Voltage - Input (Min) | 50 V dc | Resistance - Initial (Ri) (Min) | 110 mOhms |
Mechanical
| Depth | 0.85mm | Width | 0.85 mm |
| Height | 1.6mm | Length | 1.1mm |
| Weight | 0.0001 | Packaging | Tape & Reel (TR) |
| Height (Max) | 0.047" (1.20mm) | Mounting Type | Surface Mount |
| Connector Type | :SMD | Package / Case | Horizontal, 4 PC Pad |
| Size / Dimension | 0.063" L x 0.033" W (1.60mm x 0.85mm) | Termination Style | SMD |
Product Info
| Type | SMD Common Mode Line Filter | Series | WE-CNSW |
| Number of Lines | 2 | ||
Environmental
| Operating Temperature | -40°C ~ 105°C | ||
