7448640413
| Manufacturer | |
| Description | CHOKE POWER LINE 5.6MH .8A Wurth 5.6mH Manganese Zinc Ferrite Leaded Inductor, 800mA Idc, 420mΩ Rdc |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 732-1675-5 | Standard Package | 345 |
Compliance
| RoHS | Compliant | ||
Electrical
| Current | 800mA | Inductance | 5.6mH |
| Filter Type | Power Line | DC Resistance (DCR) | 420 mOhm |
| Current Rating (Max) | 800mA | Resistance - Initial (Ri) (Min) | 420mΩ |
Mechanical
| Depth | 16.6mm | Height | 22.5mm |
| Length | 21.2mm | Packaging | Tube |
| Height (Max) | 0.886" (22.50mm) | Pitch - Post | 13mm |
| Core Material | Manganese Zinc Ferrite | Mounting Type | Through Hole |
| Package / Case | Vertical, 4 PC Pin | Size / Dimension | 0.835" L x 0.654" W (21.20mm x 16.60mm) |
Product Info
| Number of Lines | 2 | ||
Environmental
| Operating Temperature | -25°C ~ 125°C | ||
