690357101272
| Manufacturer | |
| Description | CONN 2.54MM MALE STR PCB TH 12P Wurth Elektronik 6903 Series 1.27, 2.54mm Pitch 12 Way 2 Row Straight PCB Header, Solder Termination, 1.5A Headers & Wire Housings WR-MM CONN 2.54MM MALE STR PCB TH 12P PLUG, 2.54/1.27MM, 12WAY Wurth Elektronik WR-MM MiniModule 系列 1.27 mm, 2.54 mm节距 12路 (2排) 直 PCB 针座, 焊接端接, 1.5A , 表面安装 |
| Category |
Business
| Other Names | 732-1986-5 | Standard Package | 31 |
Compliance
| RoHS | Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85366990 | Material Flammability Rating | UL 94 V-0 |
Electrical
| Range deg/s | :WURTH ELEKTRONIK - WR-MM Series | Voltage Rating | 100 V ac |
| Current Rating (Max) | 1.5A | Insulation Resistance | 1000 MOhms |
Mechanical
| Color | Red | Pitch | 0.100" (2.54mm) |
| Weight | 0.39 | Packaging | Tube |
| Row Spacing | 0.100" (2.54mm) | Termination | Press-Fit |
| Contact Type | Male Pin | Mounting Type | Through Hole |
| Connector Type | Header, Shrouded | Contact Finish | Tin |
| Number of Rows | 2 | Contact Material | Phosphor Bronze |
| Housing Material | Polybutylene Terephthalate (PBT) | Termination Style | Through Hole |
| 1st Contact Gender | Pin (Male) | Number of Contacts | 12 |
| Contact Termination | :Through Hole Vertical | Number of Positions | 12 |
Product Info
| Type | Board to Board | Gender | :Plug |
| Series | 6903 | Product Type | Connectors |
| Application Specifics | Wire-to-Board | Number of Positions Loaded | All |
Environmental
| Operating Temperature | - 40 C to + 105 C | ||
Documents & Media
Similar Parts
690367281276
Wurth Electronics Inc
CONN 2.54MM SMD FEMALE POLAR 12P Wurth Elektronik 6903 Series 2.54, 1.27mm 12 Way 2 Row Right Angle PCB Socket Surface Mount Board to Board Headers & Wire Housings WR-MM CONN 2.54MM SMD FEMALE POLAR 12P SOCKET, 2.54/1.27MM, SMT, 12WAY Wurth Elektronik 6903 系列 2行 12路 直角 1.27 mm, 2.54 mm节距 表面贴装 印刷电路板插座, 板对板
690368171272
Wurth Electronics Inc
CONN 2.54MM FEM ANGLED POLAR 12P Wurth Elektronik 6903 Series 2.54, 1.27mm 12 Way 2 Row Straight PCB Socket Through Hole Board to Board Headers & Wire Housings WR-MM CONN 2.54MM FEM ANGLED POLAR 12P SOCKET, 2.54/1.27MM, R/A, 12WAY Wurth Elektronik 6903 系列 2行 12路 直 1.27 mm, 2.54 mm节距 通孔 印刷电路板插座, 板对板
690367181272
