MKS2C022201A00KSSD
| Manufacturer | |
| Description | Film Capacitors 63V .022uF 10% FR 22nF 63V 10% P5 MKT WIMA 22nF ±10% 40 V ac, 63 V dc Through Hole Polyester Film Capacitor CAPACITOR, 0.022UF, 63V Capacitor 22 nF 63 VDC / 40 VAC, MKS2C022201A00KSSD, Wima WIMA MKS2 系列 22nF 通孔 聚酯电容器 (PET), ±10%容差, 40 V 交流，63 V 直流 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 5000 | Product | Metallized Polyester Film Capacitors |
| Unit Pack | 5000 | Part # Aliases | MKS2-.022/63/10 |
| Product Category | Film Capacitors | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85322500 | Automotive | NO |
Electrical
| Voltage | 40 V ac, 63 V dc | Tolerance | 10 % |
| Capacitance | 0.022 uF | Range deg/s | :WIMA - MKS2 Series |
| Power Factor | :0.008 | Voltage - Test | 100.8V |
| Voltage Rating | 63 V | Voltage - Supply | 63V |
| Capacitance - Input | :- | Frequency Stability | :1kHz |
| Resistance Tolerance | -10% | Capacitance @ Frequency | 22nF |
| Dissipation Factor (DF) | 8 | ||
Mechanical
| Depth | 2.5mm | Pitch | 5mm |
| Width | 2.5 mm | Height | 6.5mm |
| Length | 7.2mm | Weight | 0.0019 |
| Packaging | Bulk | Lead Spacing | 5 mm |
| Pin Diameter | 0.5 mm | Pitch - Post | 5mm |
| Mounting Type | Through Hole | Terminal Type | :Radial Leaded |
| Number of Pins | :2 | Package / Case | 6.5 mm |
| Length - Overall | 6-2mm | Size / Dimension | 2.5 x 6.5 x 7.2mm |
| Termination Style | Radial | Length - Lead Wire | :6mm |
| Dielectric Material | Polyester | Pulse Width Distortion (Max) | 35V/µs |
| Diameter - Outside, Non-Expanded | 2.5mm | ||
Product Info
| Type | Metallized Polyester (PET) Capacitors PCM 5 mm | Style | RADIAL |
| Series | MKS2 | Matchcode | FR22N563V10% |
| Product Type | General Purpose | Standard Leadtime | 11 weeks |
Environmental
| Rated Life | :300000 hours @ 40°C | Operating Temperature | - 55 C to + 100 C |
| Temperature Coefficient | :+330ppm/°C | Maximum Temperature Limit | 100°C |
| Temperature Coefficient (Typ) | :330ppm/°C | ||
