Manufacturer	Weidmüller Holding AG & Co. KG
Description	MPC 071207 ST 75 X 125 X 75 -EA ENCLOSURE MPC ST 75X125X75MM
Category	Hardware and Thermal SolutionsBoxesBoxes

RoHS	Lead free / RoHS Compliant	IEC Standard	27-18-92-90
Standard Number	31-26-15-02	Protection Features	IP66, IP67

Frequency	27-14-44-30	Connector Impedance	4 polyamide crosshead screws
Connector - Voltage Input	1x6

Color	Gray, Clear Cover/Door	Depth	75 mm
Width	125 mm	Height	4.921" (125.00mm)
Weight	0.472 lb (214.1g)	Material	Plastic, Polycarbonate
Shell Style	left, top, right, Bottom	Area (L x W)	8.72" (56.3cm)
Mounting Type	thanks to self-tapping screws	Shell Plating	Polyurethane
Depth (Inches)	2.953 inch	Width (Inches)	4.921 inch
Height (Inches)	2.953 inch	Size / Dimension	2.953" L x 2.953" W (75.00mm x 75.00mm)
Thread/Screw/Hole Size	1	Industry Recognized Mating Diameter	1

Type	MPC 07/12/07 trsp	Design	Cover Included
ETIM 6*0	EC000261	Features	PCB Supports, Sealed
GTIN (EAN)	4032248009558	Applications	Building systems and technology, Transportation, Packaging industry, Machine construction
Shipping Info	Shipped from Digi-Key	Container Type	Box
Engineering Data	EPLAN	Firmware Version	MPC, Empty enclosure, Height: 75 mm, Width: 125 mm, Depth: 75 mm, Material: Polycarbonate, Light Grey, Transparent, Light Grey, Transparent
Descriptive Text Technical Data	It is possible to mount the WDU terminal blocks on a TS 35.

Ratings	IP66, IP67	ET (Volt-Time)	EC000058
Ingress Protection	27-14-91-07	Operating Temperature	-50 °C
