9526930000
| Manufacturer | |
| Description | ENCLOSURE K5 AL M4 STUD |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | IEC Standard | 27-18-05-02 |
| Approval Agency | IECEx IBE13.0002X | Standard Number | 31-26-15-02 |
| Protection Features | IP66, IP67 | Approval Agency Marking | 44536-07 |
Electrical
| Frequency | 27-18-05-02 | Connector Impedance | M5 torx stainless steel screws with slot |
| Connector - Voltage Input | 1x10 | ||
Mechanical
| Color | Unpainted | Depth | 90 mm |
| Width | 170 mm | Height | 3.543" (90.00mm) |
| Weight | 3.4 lbs (1.5kg) | Material | Metal, Aluminum |
| Shell Style | left, right | Area (L x W) | 34.3" (221cm) |
| Mounting Type | Holes 6 mm | Shell Plating | Silicone |
| Strap Closure | IBExU 12ATEX1144U | Contact Finish | untreated |
| Depth (Inches) | 3.543 inch | Torque - Screw | 2.5 Nm |
| Wall Thickness | 4.6 mm | Width (Inches) | 6.693 inch |
| Height (Inches) | 5.118 inch | Size / Dimension | 6.693" L x 5.118" W (170.00mm x 130.00mm) |
| Material Thickness | 4.6 mm | Thread/Screw/Hole Size | 3 |
| Impact Capacity per Cycle | 7.00 J | Industry Recognized Mating Diameter | 4 ???New24??? |
Product Info
| Type | KLIPPON K5 EX | Design | Cover Included |
| ETIM 6*0 | EC002503 | Features | Sealed |
| GTIN (EAN) | 4032248019069 | Description | The accessory sets contain the necessary mounting material. Necessary on use of 1 hinge per longitudinal side. |
| Applications | Explosive risk zone, Process industry, Transportation, Packaging industry, Marine engineering, Machine construction, Harbour facilities | Legend (Text) | The colours of painted enclosures may vary under certain circumstances. **Delivery time available on request. |
| Shipping Info | Shipped from Digi-Key | Container Type | Box |
| Engineering Data | EPLAN | Firmware Version | Klippon K, Empty enclosure, Aluminium enclosure, Height: 130 mm, Width: 170 mm, Depth: 90 mm, Material: Aluminium AlSi12, untreated, Silver, Silver |
| Other Specifications | 1x8 | Descriptive Text Technical Data | The mounting rails are designed to be installed directly.Assembly with terminals provides for 10 mm clearance to the ends of the mounting rail.Ordering recommendations:TS 35 mounting rail (screw-type terminals) WDU 2.5 1020000000 / (tension clamp terminals) ZDU 2.5 1608510000*For fitting the enclosures with terminal blocks, please refer to the Terminal block catalogue or the SAK series. We recommend BK 6 or BK 6 CRN (0625220000) for vertical installations. There are no specified mounting options available for mounting the enclosure in a vertical position. There are no pre-defined mounting points set within this enclosure for installing internal equipment in a vertical position. |
Environmental
| Ratings | IP66, IP67 | ET (Volt-Time) | EC000049 |
| Ingress Protection | 27-18-05-02 | Operating Temperature | 135 °C |
