点击放大查看
9526850000
| Manufacturer | |
| Description | ENCLOSURE K11 AL M4 STUD |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | IEC Standard | 27-18-05-02 |
| Approval Agency | IECEx IBE13.0002X | Standard Number | 31-26-15-02 |
| Protection Features | IP66, IP67 | Approval Agency Marking | 44536-07 |
Electrical
| Frequency | 27-18-05-02 | Connector Impedance | M4 torx stainless steel screws with slot |
Mechanical
| Color | Unpainted | Depth | 57 mm |
| Width | 75 mm | Height | 2.244" (57.00mm) |
| Weight | 0.617 lb (279.87g) | Material | Metal, Aluminum |
| Shell Style | left, right | Area (L x W) | 9.30" (60.0cm) |
| Mounting Type | Holes 4 mm | Shell Plating | Silicone |
| Strap Closure | IBExU 12ATEX1144U | Contact Finish | untreated |
| Depth (Inches) | 2.244 inch | Torque - Screw | 2.5 Nm |
| Wall Thickness | 4 mm | Width (Inches) | 2.953 inch |
| Height (Inches) | 3.15 inch | Size / Dimension | 2.953" L x 3.150" W (75.00mm x 80.00mm) |
| Material Thickness | 4 mm | Thread/Screw/Hole Size | 1 |
| Impact Capacity per Cycle | 7.00 J | Industry Recognized Mating Diameter | 1 |
Product Info
| Type | KLIPPON K11 EX | Design | Cover Included |
| ETIM 6*0 | EC002503 | Features | Sealed |
| GTIN (EAN) | 4032248019144 | Description | The accessory sets contain the necessary mounting material. Necessary on use of 1 hinge per longitudinal side. |
| Applications | Explosive risk zone, Process industry, Transportation, Packaging industry, Marine engineering, Machine construction, Harbour facilities | Legend (Text) | The colours of painted enclosures may vary under certain circumstances. **Delivery time available on request. |
| Shipping Info | Shipped from Digi-Key | Container Type | Box |
| Engineering Data | EPLAN | Firmware Version | Klippon K, Empty enclosure, Aluminium enclosure, Height: 80 mm, Width: 75 mm, Depth: 57 mm, Material: Aluminium AlSi12, untreated, Silver, Silver |
| Descriptive Text Technical Data | *Please refer to the Terminal Block Catalogue or the SAK Series for more information about populating the enclosures with terminal blocks. We recommend at most one BK 6 or BK 6 CRN (0625220000) in vertical installations. There are no pre-defined mounting points set within this enclosure for installing internal equipment in a vertical position. | ||
Environmental
| Ratings | IP66, IP67 | ET (Volt-Time) | EC000049 |
| Ingress Protection | 27-18-05-02 | Operating Temperature | 135 °C |
