点击放大查看
8836630000
| Manufacturer | |
| Description | JPTA100MS 24VDC PNP M12 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| RoHS | Conform | IEC Standard | 27-37-16-05 |
| Certification | E141197 | Standard Number | 30-21-19-17 |
Electrical
| Circuit | SPST-NO (1 Form A) | Frequency | 27-14-23-90 |
| Delay Time | Fixed, 0.10 Sec | Output Type | Solid State Relay |
| Current - Test | 0.4 A | Voltage Rating | 32 V |
| Delay Time - OFF | 100 ms | Voltage - Supply | 24VDC |
| Current - Switching | 400 mA | Current Rating - DC | 3,5...7,0...10,0 mA |
| Timing Initiate Method | Input Voltage | Voltage - Switching DC | 30 V |
| Contact Rating @ Voltage | 0.4A @ 30VDC | Voltage - Supply, Digital | 18...24...30 V DC |
| Impulse Discharge Current (8/20us) | 330 V | ||
Mechanical
| Depth | 83 mm | Width | 36 mm |
| Height | 14.4 mm | Weight | 55 g |
| Termination | M12 plug/socket, A-coded | Mounting Type | Socket |
| Depth (Inches) | 3.268 inch | Width (Inches) | 1.417 inch |
| Height (Inches) | 0.567 inch | Termination Style | Plug In |
| Number of Contacts | 1 | Contact Layout, Typical | NO contact |
Product Info
| Type | JPTA100MS 24VDC PNP M12 | Duration | 1 ms |
| ETIM 6*0 | EC001439 | Function | Off-Delay |
| GTIN (EAN) | 4032248544264 | Relay Type | Integrated |
| Description | Retaining clipJP CLIP M: 8778490000 | Engineering Data | EPLAN |
| Firmware Version | JACKPAC, Pulse stretcher, No. of contacts: 1, NO contact, Rated control voltage: 18...24...30 V DC, Continuous current: 0.4 A, M12 plug/socket, A-coded | Other Specifications | I |
| Timing Adjustment Method | Fixed | ||
Environmental
| ET (Volt-Time) | EC001439 | Ingress Protection | 2 |
| Operating Temperature | 0 °C...60 °C | ||
