1965740000

Manufacturer	Weidmüller Holding AG & Co. KG
Description	SOLDER CONN GREY
Category	Connector SolutionsTerminal BlocksScrew Terminal Blocks

对参数有疑问？问 AI 助手

Business

Standard Package

RoHS	Lead free / RoHS Compliant	Compliance	IEC 60664-1, IEC 61984
Certification	200039-1830694	Approval Agency	E60693
Standard Number	30-21-18-11	Approval Agency Marking	Specifications are maximum values, details - see approval certificate.
Material Flammability Rating	V-0

Color	Gray	Width	0.394" (10.00mm)
Height	31.5 mm	Length	15.5 mm
Weight	7.1 g	Packaging	Box
Wire Gauge	8-22 AWG	Termination	Screw / solder connection
Rivet Length	M 3.5	Torque - Min	0.8 Nm
Contact Finish	tinned	Width (Inches)	0.394 inch
Height (Inches)	1.24 inch	Length (Inches)	0.61 inch
Panel Thickness	0.039 ~ 0.158" (1.0 ~ 4.0mm)	Contact Material	E-Cu
Height - Overall	31.5 mm	Panel Mount Type	2 Piece
Stripping Length	13 mm	Inlet/Outlet Size	180°
Color - Connectors	Grey	Insulation Material	Wemid (PA)
Pin Size - Above Flange	6 mm²	Pin Size - Below Flange	0.5 mm²
Diameter - Large Outside	10 mm²	Diameter - Small Outside	0.5 mm²
Wire Gauge or Range - AWG	AWG 10	Wire Gauge or Range - mm2	AWG 22
Rear Panel Wire Connection	Circular Clamp, Solder Hook	Front Panel Wire Connection	Bolt/Screw Clamp - Wire Entry 90° to Panel
Torque - Max Momentary (oz-in / mNm)	1.8 Nm

Note	Clearance and creepage distances to other components must be devised in accordance with the relevant application standard. This can be achieved in the device by full encapsulation or by the use of additional spacer plates. Rated data refer only to the component itself. Clearance and creepage distances to other components are to be designed in accordance with the relevant application standards. Colours: BL = black; GN/YL = green yellow; none = grey Additional colours on request VWGK: Rated voltage plastic walls: 1 - 4 mm = 500 V; metal walls: 1 - 4 mm = 500 V	Type	VWGK 6
Series	OMNIMATE Power - series WGK	ETIM 6*0	EC001283
Features	IEC: 500 V / 41 A / 0.5 - 10 mm²UL: 300 V / 50 A / AWG 22 - AWG 10	GTIN (EAN)	4032248671250
Legend (Text)	RAL 7035	Customer Fitted	No
Engineering Data	EPLAN	Firmware Version	OMNIMATE Power - series WGK, Feedthrough terminal, Rated cross-section: 6 mm², Wemid (PA), Grey, Direct mounting, Feed-through (bushing)
Number of Levels	1	Tool Type Feature	0.8 x 4.0
Positions Per Level	1
