1964420000
| Manufacturer | |
| Description | IE-BI-LCD-MM-C -EA CONN FIBER LC RECEPT DUPLX |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | IE-BI-LCD-MM-C | Standard Package | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | IEC Standard | 19-07-01-22 |
| Approval Agency | POCC DE.ME25.B01411.pdf | Standard Number | 30-21-18-01 |
| Protection Features | IP67 with housing | ||
Electrical
| Frequency | 19-17-01-25 | Reflection | 30dB |
| Return Loss | ≥ 30 dB | Insertion Loss | ≤ 0.4 dB |
| Attenuation - Typ | 0.4dB | ||
Mechanical
| Weight | 14.9 g | 1st Connector | LC Duplex |
| Body Material | Polybutylene Terephthalate (PBT) | Housing Color | Beige |
| Mounting Type | Free Hanging (In-Line) | Connector Type | Receptacle |
| Fastening Type | Push-Pull | Connector Style | LC |
| Housing Material | Zinc Die Cast | Connector/Contact Type | IEC 61754-20 |
Product Info
| Mode | Multimode | Type | IE-BI-LCD-MM-C |
| ETIM 6*0 | EC001122 | Fiber Type | Multimode |
| GTIN (EAN) | 4032248649037 | Description | Bulkhead insert LC duplex, multimode |
| Configuration | Connector and flange insert for variant 1, 4 and 14 housings | Simplex/Duplex | Duplex |
| Firmware Version | LC insert, Bulkhead insert LC duplex, multimode | ||
Environmental
| Mating Cycles | 1000 | ET (Volt-Time) | EC001121 |
| Humidity Range | 0...85 % rel. humidity | Ingress Protection | 27-14-40-17 |
| Operating Temperature | -40°C ~ 70°C | ||
