1963590000
| Manufacturer | |
| Description | IE-PS-RJ45-TH-BK -EA CONN MOD PLUG 8P8C SHIELDED |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | IE-PS-RJ45-TH-BK | Standard Package | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | UL Listing | DUXR2.E316369.pdf |
| IEC Standard | 27-44-09-90 | Qualification | CC-Link IE-PS-RJ45-TH-BK.PDF |
| Approval Agency | E316369 | Standard Number | 30-21-18-10 |
| Protection Features | IP20 | ||
Electrical
| Frequency | 19-17-01-25 | PoE Ports | conforming to IEEE 802.3af |
| Magnification | C1 | Contact Resistance | ≤ 20 mΩ |
| Dielectric Strength | ≤ 1500 V DC | Voltage - Breakdown | ≤ 1000 V DC |
| Current Rating (Max) | 1A | Insulation Resistance | 500 MΩ |
| Current Rating - Appliance Inlet | 1 A | ||
Mechanical
| Color | Translucent - Clear | Weight | 10.4 g |
| Packaging | Bulk | Shielding | Shielded |
| Cable Type | Round Cable, Solid or Stranded Wires | Wire Gauge | 24-27 AWG |
| Termination | IDC | 1st Connector | RJ45 |
| Core Diameter | 0.36...0.51 mm | Cable Diameter | 0.46...0.61 mm |
| Contact Finish | Gold | Probe Material | Polycarbonate PC, UL 94 V-0 |
| Shield Material | Brass | Contact Material | Phosphor Bronze |
| Housing Material | Polycarbonate (PC) | Color - Connectors | Miscellaneous |
| Cross Section Shape | AWG 27...AWG 24 | Insulation Material | Polycarbonate PC, UL 94 V-0 |
| Connector/Contact Type | IEC 60603-7-51 | 1st Connector Orientation | z1755b-07-E.pdf |
| Diameter - Protective Tube | 7.3 mm | 2nd Connector Mounting Type | IDC |
| Outside Cable Diameter (Min) | 89 N | Diameter - Outside, Non-Expanded | 5 mm |
Product Info
| Type | IE-PS-RJ45-TH-BK | ETIM 6*0 | EC001121 |
| Features | Strain Relief | GTIN (EAN) | 4032248645695 |
| Description | Plug with bending protection sleeve in black | Configuration | Connects piercing contacts and shielded connections in one step, retro-fit for kink-prevention sleeves, Multi-port compatible |
| Firmware Version | RJ45 crimp plug, Plug with bending protection sleeve in black, Cat.6A / Class EA (ISO/IEC 11801 2010) | Installation Type | STEADYTEC® assembly instruction RJ45 crimp connector_EN_HD.mp4 |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) | ||
Environmental
| Ratings | Cat6a | Mating Cycles | 750 |
| ET (Volt-Time) | EC001121 | Ingress Protection | IP20 |
| Operating Temperature | -40 °C...70 °C | ||
