1820840000

Manufacturer	Weidmüller Holding AG & Co. KG
Description	Conn Feed-Thru 2 POS ST 150A TERMINAL WDU 50N
Category	Connector SolutionsTerminal BlocksScrew Terminal Blocks

对参数有疑问？问 AI 助手

Business

Standard Package

Bulk

RoHS	Lead free / RoHS Compliant	Standards	IEC 60947-7-1
Compliance	E60693	Protection	No
IEC Standard	27-14-11-20	Certification	200039-1057876
Safety Category	KEMA98ATEX1683U	Standard Number	30-21-18-11
Approval Agency Marking	IECEXULD14.0005U	Declaration of Conformity	DE_PT1001_20160418_805_ISSUE01.pdf
Material Flammability Rating	UL94 V-0

Current	126 A	Frequency	27-14-11-20
Range deg/s	70 mm²	Current - UL	150A
Voltage - UL	600V	Current - IEC	150A
Voltage - IEC	1000V	Voltage - Max	690 V
Voltage Rating	1,000 V	Conductor Strand	8 AWG
Current - Output	150 A	Voltage - Supply	600 V
Number of Elements	1	Current Rating (Max)	192 A
Insulation Resistance	0.21 mΩ	Current - Output (Typ)	150 A
Number of Outputs and Type	1	Voltage - Supply, Single (V+)	600 V
Voltage - Breakdown (V(BR)GSS)	8 kV	Voltage Rating - Appliance Inlet	600 V
Voltage - Output (Typ) @ Distance	600 V	Minimum Core Cross Section (Amin) mm2	6 mm²

Color	Beige	Depth	69.6 mm
Width	18.5 mm	Height	70 mm
Weight	84.38 g	Material	Wemid
Blade Size	S4 (DIN 6911)	Wire Gauge	(1/0)-10 AWG
End Feature	No	Opening Size	closed
Rivet Length	M 6	Torque - Min	3.5 Nm
Housing Color	Dark Beige	Mounting Type	Straight
Connector Type	Screw connection	Depth (Inches)	2.74 inch
Mounting Rails	TS 35	Number of Rows	2
Width (Inches)	0.728 inch	Height (Inches)	2.756 inch
Stripping Length	24mm	Terminal - Width	18.5mm
Termination Style	Screw	Wire Gauge - Ends	10 AWG
Color - Connectors	Dark Beige	Number of Positions	2
Material - Insulation	Thermoplastic, Wemid	Width / Cross Section	16 mm²
Wire Gauge or Range - AWG	1/0-10 AWG	Wire Gauge or Range - mm2	10-70mm²
Number of Positions/Bay/Row	2	Torque - Max Momentary (oz-in / mNm)	6 Nm

Type	Feed-Thru	ETIM 6*0	EC000897
Direction	on side	GTIN (EAN)	4032248318117
Engineering Data	EPLAN	Firmware Version	Screw connection, for screwable cross-connection, closed
Number of Levels	1	Installation Type	Direct mounting
Number of Circuits	1	Operating Position	NTI_ IECEx_WDU-WPE 50N.pdf
Independent Circuits	No	Other Specifications	No
Number of A/D Converters	CFAT_WDU 50N.pdf	Number of Positions (Convert From)	2

Rated Life	50 mm²	ET (Volt-Time)	EC000897
Ingress Protection	3	Operating Temperature	For operating temperature range see EC Design Test Certificate / IEC Ex-Certificate of Conformity
