1162850000
| Manufacturer | |
| Description | TERMINAL WMF 2.5 FU BLZ PE |
| Category |
Business
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | IEC 60947-7-2, IEC 61984, In accordance with IEC 60947-7-1, IEC 60947-7-3 |
| IEC Standard | 27-14-11-16 | Certification | 200039-1057876 |
| Approval Agency | E60693 | Declaration of Conformity | DE_PT1033_20160418_918_ISSUE01.pdf |
| Material Flammability Rating | UL94 V-0 | ||
Electrical
| Current | 17 A | Voltage | 300 V |
| Frequency | 27-14-11-16 | Range deg/s | 0.5 mm² |
| Current - UL | 17A | Voltage - UL | 300V |
| Current - IEC | 6.3A | Voltage - IEC | 150V |
| Voltage Rating | 150 V | Coupling Factor | 26 AWG |
| Conductor Strand | 26 AWG | Current - Output | 10 A |
| Overload Protection | 1.6 W at 6.3 A @ 44°C | Current Rating (Max) | 6.3 A |
| Insulation Resistance | 1.33 mΩ | Power Line Protection | 4 W at 6.3 A @ 61°C |
| Current - Output (Typ) | 17 A | Voltage - Breakdown (V(BR)GSS) | 8 kV |
| Voltage Rating - Appliance Inlet | 300 V | Voltage - Output (Typ) @ Distance | 300 V |
Mechanical
| Depth | 74 mm | Width | 5.08 mm |
| Height | 90 mm | Length | 3.543" (90.00mm) |
| Weight | 19.8 g | Material | Wemid |
| Wire Type | 2.5 mm² | Blade Size | 0.6 x 3.5 mm |
| Wire Gauge | AWG 12 | End Feature | Yes |
| Height (Max) | 2.933" (74.50mm) | Opening Size | right |
| Rivet Length | M 3 | Torque - Min | 0.5 Nm |
| Housing Color | Black | Mounting Type | DIN Rail |
| Connector Type | Screw connection | Depth (Inches) | 2.913 inch |
| Mounting Rails | TS 35 | Width (Inches) | 0.2 inch |
| Height (Inches) | 3.543 inch | Stripping Length | 10mm |
| Terminal - Width | 5.08mm | Termination Style | Plug Receptacles, Screw |
| Wire Gauge - Ends | 0.5 mm² | Color - Connectors | Black |
| Cross Hole Diameter | 0.5 mm² | Fuse Holder, Drawer | Pivoting |
| Number of Positions | 4 | Material - Insulation | Thermoplastic, Wemid |
| Width / Cross Section | 12 AWG | Wire Gauge or Range - AWG | 12-26 AWG |
| Wire Gauge or Range - mm2 | 0.5-4mm² | Torque - Max Momentary (oz-in / mNm) | 0.6 Nm |
Product Info
| Type | Plug Connection | ETIM 6*0 | EC000899 |
| Features | Disconnect, Fuse 5x20mm, LED | Direction | on side |
| Fuse Type | G-Si. 5 x 20 | GTIN (EAN) | 4032248992140 |
| Display Style | red LED | Connection Type | Plug-in connection |
| Engineering Data | EPLAN | Firmware Version | 2 screw connections - 1 plug-in connection, Fuse isolator, With PE connection, for plug-in cross-connector, One end without connector |
| Number of Levels | 2; 1 Grounded | First Conductor Mark | 12 AWG |
| Other Specifications | A3 | Number of Positions (Convert From) | 4 |
Environmental
| Rated Life | 2.5 mm² | ET (Volt-Time) | EC000902 |
| Ingress Protection | 3 | Operating Temperature | -50°C ~ 120°C |
Documents & Media
