点击放大查看

1143050000

Manufacturer	Weidmüller Holding AG & Co. KG
Description	TERMINAL WMF 2.5 BLZ
Category	Connector SolutionsTerminal BlocksDIN Rail Terminal Blocks

对参数有疑问？问 AI 助手

Business

Standard Package

100

Compliance

RoHS	Conform	Standards	IEC 61984, In accordance with IEC 60947-7-1
Protection	No	IEC Standard	27-14-11-20
Certification	200039-1057876	Approval Agency	E60693
Declaration of Conformity	DE_PT1031_20160418_885_ISSUE01.pdf	Material Flammability Rating	UL94 V-0

Electrical

Current	20 A	Voltage	300 V
Frequency	27-14-11-20	Range deg/s	0.5 mm²
Current - UL	20A	Voltage - UL	300V
Current - IEC	24A	Voltage - IEC	250V
Voltage Rating	250 V	Coupling Factor	26 AWG
Conductor Strand	26 AWG	Current - Output	10 A
Number of Elements	1	Current Rating (Max)	32 A
Insulation Resistance	1.33 mΩ	Current - Output (Typ)	26 A
Number of Outputs and Type	1	Voltage - Breakdown (V(BR)GSS)	8 kV
Voltage Rating - Appliance Inlet	300 V	Voltage - Output (Typ) @ Distance	300 V

Mechanical

Depth	44.5 mm	Width	5.08 mm
Height	90 mm	Length	3.543" (90.00mm)
Weight	10.78 g	Material	Wemid
Wire Type	2.5 mm²	Blade Size	0.6 x 3.5 mm
Wire Gauge	AWG 12	End Feature	Yes
Height (Max)	1.772" (45.00mm)	Opening Size	right
Rivet Length	M 3	Torque - Min	0.5 Nm
Housing Color	Beige	Mounting Type	DIN Rail
Connector Type	Screw connection	Depth (Inches)	1.752 inch
Mounting Rails	TS 35	Width (Inches)	0.2 inch
Height (Inches)	3.543 inch	Stripping Length	10mm
Terminal - Width	5.08mm	Termination Style	Plug Receptacles, Screw
Wire Gauge - Ends	0.5 mm²	Color - Connectors	Dark Beige
Cross Hole Diameter	0.5 mm²	Number of Positions	3
Material - Insulation	Thermoplastic, Wemid	Width / Cross Section	12 AWG
Wire Gauge or Range - AWG	12-26 AWG	Wire Gauge or Range - mm2	0.5-4mm²
Number of Positions/Bay/Row	3	Torque - Max Momentary (oz-in / mNm)	0.6 Nm

Product Info

Type	Plug Connection	ETIM 6*0	EC000897
Direction	on side	GTIN (EAN)	4032248926022
Connection Type	Plug-in connection	Engineering Data	EPLAN
Firmware Version	2 screw connections - 1 plug-in connection, for plug-in cross-connector, One end without connector	Number of Levels	1
First Conductor Mark	12 AWG	Independent Circuits	No
Other Specifications	No	Number of Positions (Convert From)	3

Environmental

Rated Life	2.5 mm²	ET (Volt-Time)	EC000902
Ingress Protection	3	Operating Temperature	-50°C ~ 120°C

Documents & Media

PDF Document

Modular Terminal Blocks Catalog
