1068830000
| Manufacturer | |
| Description | CONN MOD JACK 8P8C |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Compliance | cs107367A.pdf |
| Protection | IEC 60529 | UL Listing | DUXR.E316369.pdf |
| Certification | E316369 | Protection Features | IP65 |
| Material Flammability Rating | V-0 | ||
Electrical
| Frequency | 27-25-05-04 | Voltage - Nominal | 24 V |
| Contact Resistance | ≤ 20 mΩ | Insulation Resistance | > 500 MΩ |
| Current - Collector Pulsed (Icm) | 16 A | Minimum Core Cross Section (Amin) mm2 | 0.75 mm² |
Mechanical
| Width | 80 mm | Height | 52 mm |
| Length | 100 mm | Weight | 474 g |
| LED Color | Does Not Contain LED | Packaging | Bulk |
| Shielding | 360° shield contact | Wire Gauge | AWG 26 |
| Orientation | Straight | Contact Size | Gold over nickel |
| 2nd Connector | Tension clamp | Holding Force | ≤ 30 N |
| Cable Material | TPE | Connector Type | Jack with Power Jack |
| Number of Rows | 1 | Width (Inches) | 3.15 inch |
| Height (Inches) | 2.047 inch | Length (Inches) | 3.937 inch |
| Housing Material | Zinc diecast, nickel-plated | Cable Termination | PROFINET |
| Pitch - Connector | ≤ 100 | Color - Connectors | Silver grey |
| Conductor Material | NBR | Cross Section Shape | 13 |
| Connector/Contact Type | Gold over nickel | Contact Length - Mating | ≤ 1500 V DC |
| Contact Material - Post | Copper alloy | 1st Connector Orientation | z1755b-07-D.pdf |
| 2nd Connector Orientation | ac107535.pdf | Center Conductor Diameter | 12 mm |
| Wire Gauge or Range - AWG | AWG 22 | Rear Panel Wire Connection | 2.5 mm² |
| Front Panel Wire Connection | 2.5 mm² | ||
Product Info
| Type | IE-CD-V14MRJ/VAPM24V-FJ | ETIM 6*0 | EC000018 |
| GTIN (EAN) | 4032248824014 | Communications | DIN EN 61918 Draft 02.2007, ISO / IEC 24702:2006, ISO / IEC 11801:2002, ANSI / TIA / EIA-568-B.2-10, EN 50173-1:2007 |
| Module Capacity | Silver | Number of Ports | 2 |
| Firmware Version | Junction box, FreeCon, RJ45 module, Power | Connection Method | IDC |
| Application Specifics | PROFINET installation instructions | Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
Environmental
| Mating Cycles | 750 | ET (Volt-Time) | EC000018 |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | Operating Temperature | -40°C ~ 70°C |
