1068820000
| Manufacturer | |
| Description | CONN MOD JACK 8P8C |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | IE-CD-V14MRJ/VAPM2 | Standard Package | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | UL Listing | DUXR.E316369.pdf |
| Certification | E316369 | Protection Features | IP65 |
| Material Flammability Rating | V-0 | ||
Electrical
| Frequency | 27-25-05-04 | Coupling Factor | Gold over nickel |
| Current - Carry | 1 A | Voltage - Nominal | 24 V |
| Contact Resistance | ≤ 20 mΩ | Insulation Resistance | > 500 MΩ |
| Current - Collector Pulsed (Icm) | 16 A | Minimum Core Cross Section (Amin) mm2 | 0.75 mm² |
Mechanical
| Weight | 451.6 g | LED Color | Does Not Contain LED |
| Packaging | Bulk | Orientation | Straight |
| 2nd Connector | Tension clamp | Cable Material | TPE |
| Connector Type | Jack with Power Jack | Number of Rows | 1 |
| Housing Material | Zinc diecast, nickel-plated | Pitch - Connector | 2 |
| Conductor Material | NBR | Cross Section Shape | 13 |
| Connector/Contact Type | Gold over nickel | Contact Length - Mating | ≥ 1500 V DC |
| Contact Material - Post | Copper alloy | 1st Connector Orientation | z1755b-07-D.pdf |
| 2nd Connector Orientation | ac107535.pdf | Center Conductor Diameter | 12 mm |
| Front Panel Wire Connection | 2.5 mm² | ||
Product Info
| Type | IE-CD-V14MRJ/VAPM24V-C-MA | ETIM 6*0 | EC001262 |
| GTIN (EAN) | 4032248823918 | Number of Ports | 2 |
| Firmware Version | Junction box, FreeCon, RJ45, Coupling, Power | Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
Environmental
| Mating Cycles | ≥ 100 | ET (Volt-Time) | EC001262 |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | Operating Temperature | -40°C ~ 70°C |
