1041180000
| Manufacturer | |
| Description | Conn Feed-Thru 4 POS Screw ST 20A TERM DUAL LEVEL PLUGGABLE BLUE |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | WDK25NPLUGGABLE BL | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | Material Flammability Rating | UL94 V-0 |
Electrical
| Current - UL | 20A | Voltage - UL | 300V |
| Current - IEC | 24A | Voltage - IEC | 400V |
Mechanical
| Color | Blue | Wire Gauge | 12-30 AWG |
| Termination | Screw | Housing Color | Blue |
| Mounting Type | Straight | Number of Rows | 4 |
| Stripping Length | 10mm | Terminal - Width | 5.1mm |
| Termination Style | Screw | Number of Positions | 4 |
| Material - Insulation | Thermoplastic, Wemid | Wire Gauge or Range - AWG | 12-30 AWG |
| Wire Gauge or Range - mm2 | 0.5-4mm² | ||
Product Info
| Type | Feed-Thru | Number of Levels | 2 |
| Number of Circuits | 2 | ||
