RSSD10X50A10R0JS06
| Manufacturer | |
| Description | Wirewound Resistors - Chassis Mount 25W 10ohm 5% fireproof RESISTOR 10 OHM 25W 5% WW Vishay 10Ω ±5% 25W High Power Wirewound Adjustable Resistor ±75ppm/°C Wirewound Resistors 25W 10ohm 5% fireproof RESISTOR, WW 25W 5% 10R Vishay RSSD 系列 25W 10Ω 5% 高功率线绕可调电阻器 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 25 | Product | Power Resistors Wirewound Vitreous Enamel |
| Unit Pack | 25 | Other Names | RSSD-10D |
| Standard Package | 25 | Factory Pack Quantity | 25 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85332900 |
Electrical
| Tolerance | 5 % | Resistance | 10 Ohms |
| Range deg/s | :VISHAY - RSSD Series | Power (Watts) | 25W |
| Power - Rated | 25 W | Resistance (Ohms) | 10 |
| Resistance Tolerance | :± 5% | Resistor - Base (R1) | :Solder Lug |
Mechanical
| Length | 1.969" (50.00mm) | Weight | 0.014 |
| Diameter | 0.453" OD, 0.197" ID (11.50mm x 5.00mm) | Base Type | :Tubular |
| Packaging | Bulk | Termination | Solder Lug |
| Mounting Type | Chassis Mount | Terminal Type | :AN collar |
| Package / Case | Cylinder, Tube | Size / Dimension | 11.5 mm Dia. x 50 mm L |
| Termination Style | Radial | Diameter - Outside | :11.5mm |
| Resistive Material | :Wirewound | ||
Product Info
| Type | Adjustable Wirewound Vitreous Resistors, Low Ohmic Values | Series | RSSD |
| Technology | Wire Wound | Adjustment Type | Slide |
Environmental
| Surge Rating (Watts) | :250W | Operating Temperature | - 55 C to + 450 C |
| Temperature Coefficient | 75 PPM / C | Temperature Coefficient (Typ) | :75ppm/°C |
