D2TO035CR0220FTE3
| Manufacturer | |
| Description | Thick Film Resistors - SMD 35W 0.022ohm 1% RES 0.022 OHM 35W 1% D2PAK Thick Film Resistors 35W 0.022ohm 1% RESISTOR, 35W, 1%, 0R022 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 50 | Product | Thick Film Resistors SMD |
| Unit Pack | 50 | Standard Package | 50 |
| Factory Pack Quantity | 50 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | Tariff No | 85332100 |
Electrical
| Tolerance | 1 % | Resistance | 22 mOhms |
| Range deg/s | :VISHAY - D2TO35 Series | Power (Watts) | 35W |
| Power - Rated | 35 W | Voltage Rating | 250 V |
| Resistance (Ohms) | 0.022 | Resistance Tolerance | :± 1% |
Mechanical
| Width | 8.8 mm | Height | 0.189" (4.80mm) |
| Weight | 0.0022 | Base Type | :TO-263 (D2PAK) |
| Packaging | Tube | Number of Pins | :2 |
| Package / Case | TO-263 (D2PAK) | Material Finish | :MSL 1 - Unlimited |
| Size / Dimension | 8.8 mm W x 10.1 mm L x 4.5 mm H | Termination Style | SMD/SMT |
| Resistive Material | :Thick Film | Number of Terminations | 2 |
| Supplier Device Package | TO-263 (D²Pak) | ||
Product Info
| Type | Surface Mounted Power Resistor Thick Film Technology | Series | D2TO35 |
| Features | Automotive AEC-Q200 Qualified, Non-Inductive | Composition | Thick Film |
Environmental
| Mechanical Life | New At Mouser | Operating Temperature | - 55 C to + 175 C |
| Temperature Coefficient | 1100 PPM / C | ||
