VS-GB70LA60UF
| Manufacturer | |
| Description | Trans IGBT Chip N-CH 600V 111A 4-Pin SOT-227 IGBT 600V 70A Low Side Chopper SOT227 IGBT Modules 600 volt 70 amp TRANSISTOR,IGBT,600V,70A,SOT227 Vishay N通道 IGBT 模块, 111 A 600 V, 4针 SOT-227封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | IGBT Modules | ||
Compliance
| RoHS | Compliant | Tariff No | 85411000 |
Electrical
| Frequency | 150kHz | Vgs (Max) | ±20 V |
| Transistor Type | :IGBT | Voltage - Supply | :2.23V |
| Voltage - Input (Min) | 600 V | Power Dissipation (Max) | 447 W |
| Current - Collector (Ic) (Max) | :111A | Current - Collector Cutoff (Max) | 111 A |
Mechanical
| Width | 25.7mm | Height | 12.3mm |
| Length | 38.3mm | Weight | 0.03 |
| Packaging | Tube | Mounting Type | Screw |
| Number of Pins | :4 | Package / Case | 4SOT-227 |
| Package Cooled | SOT-227 | Material Finish | :- |
| Size / Dimension | 38.3 x 25.7 x 12.3mm | Number of Positions | 4 |
Product Info
| Channel Type | N | Configuration | Single |
Environmental
| Operating Temperature | +150 °C | ||
