7101SDCGE
| Manufacturer | |
| Description | Switch Toggle ON None ON SPDT Round Toggle PC Pins 5A 250VAC 28VDC 0.4VA PC Mount with Threads Toggle SWITCH TOGGLE SPDT 5A 120V |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 50 | Unit Pack | 1 |
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SPDT | Power - Rated | 0.4@20VAC 20VDC VA |
| Voltage Rating | 28 V | Switch Function | On-On |
| Voltage - Rated AC | 250V VAC | Current Rating (Max) | 5@120VAC 28VDC A |
| Voltage - Input (Min) | 250 V | Switch Function/Rating | ON None ON |
| Voltage - DC Spark Over (Nom) | 28V VDC | ||
Mechanical
| Depth | 6.86 mm | Height | 30 mm |
| Packaging | Bulk | Actuator Type | Standard Round |
| Mounting Type | PC Mount with Threads | Terminal Type | PC Pins |
| Bushing Thread | 1/4-40 | Contact Finish | Gold/Nickel |
| Actuator Length | 12.45mm | Contact Material | Coin Silver |
| Housing Material | N/A/Stainless Steel | Length - Overall | 12.7 mm |
| Actuator Material | Brass, Chrome Plated | Termination Style | PC Pin |
| Actuator Style/Size | Round Toggle | Switch Actuation Level | SPDT |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | Material - Housing & Prism | N/A/Stainless Steel |
Product Info
| Type | Miniature | Features | Epoxy Sealed Terminals |
| Illumination | Non-Illuminated | Electrical Life | 100,000 Cycles |
Environmental
| Operating Temperature | -30 to 85 °C | Operating Temperature - Junction | 85C |
