RSSD20117A1000JB15
| Manufacturer | |
| Description | Res Wirewound 100 Ohm 5% 100W ±75ppm/°C RDL Lug Bolt-On Bulk RESISTOR 100 OHM 100W 5% WW Vishay 100Ω ±5% 100W High Power Wirewound Adjustable Resistor ±75ppm/°C RESISTOR, WW 100W 5% 100R Vishay RSSD 系列 100W 100Ω 5% 高功率线绕可调电阻器 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 20 | Unit Pack | 20 |
| Other Names | RSSD-100C | Standard Package | Boxed |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85332900 |
Electrical
| Tolerance | 5 % | Resistance | 100 Ohm |
| Range deg/s | :VISHAY - RSSD Series | Power (Watts) | 100W |
| Power - Rated | 100 W | Resistance (Ohms) | 100 |
| Resistance Tolerance | :± 5% | Resistor - Base (R1) | :Solder Lug |
Mechanical
| Height | 42 mm | Length | 4.606" (117.00mm) |
| Weight | 0.02 | Diameter | 0.866" OD, 0.496" ID (22.00mm x 12.60mm) |
| Base Type | :Tubular | Packaging | Bulk |
| Termination | Solder Lug | Mounting Type | Chassis Mount |
| Terminal Type | :AN collar | Package / Case | Cylinder, Tube |
| Length - Overall | 117 mm | Termination Style | Radial |
| Diameter - Outside | :22mm | Resistive Material | :Wirewound |
Product Info
| Type | Wirewound | Series | :RSSD |
| Technology | Wire Wound | Adjustment Type | Slide |
Environmental
| Surge Rating (Watts) | :1000W | Operating Temperature | -55 to 450 °C |
| Temperature Coefficient | ±75ppm/°C | Temperature Coefficient (Typ) | :75ppm/°C |
