HLT22507Z500R0KJ
| Manufacturer | |
| Description | Res Wirewound 500 Ohm 10% 225W ±30ppm/°C Ceramic Hi Temp Sil RDL Lug Bolt-On Skin Pack RES CHAS MNT 500 OHM 10% 225W |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | HLTA-500 | Standard Package | Bulk |
Compliance
| RoHS | Contains lead / RoHS non-compliant | ||
Electrical
| Tolerance | 10 % | Resistance | 500 Ohm |
| Power (Watts) | 225W | Power - Rated | 225 W |
| Resistance (Ohms) | 500 | ||
Mechanical
| Diameter | 33.34 mm | Packaging | Bulk |
| Lead Style | Solder Lugs | Package / Case | Radial, Tubular |
| Length - Overall | 266.7 mm | Mounting Feature | Brackets (not included) |
| Size / Dimension | 1.125" Dia x 10.500" L (28.58mm x 266.70mm) | Coating, Housing Type | Silicon Coated |
Product Info
| Type | Wirewound | Composition | Wirewound |
Environmental
| Operating Temperature | -55 to 350 °C | Temperature Coefficient | ±30ppm/°C |
Documents & Media
PDF Document
