4700-056MLF
| Manufacturer | |
| Description | Elctromechanical Filter Pi Filter FILTER EMI 5000 PF PI TYPE Feed Through Capacitors 5000pF 100Volts@85C |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 410-1198-1 | Product Category | Feed Through Capacitors |
| Standard Package | Tape & Reel | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ESD Protection | No |
Electrical
| Current | 10A | Tolerance | - 20 %, + 80 % |
| Capacitance | 5000 pF | Filter Order | 3rd |
| Voltage Rating | 100 V | Number of Channels | 1 |
| Current Rating (Max) | 10 A | Insertion Loss (Max) | 70 dB |
Mechanical
| Height | 0.090" (2.28mm) | Diameter | 2.16 mm |
| Packaging | Tape & Reel (TR) | Package / Case | Round - 0.085" Dia x 0.315" L (2.16mm x 8.00mm) |
| Size / Dimension | 0.315" L x 0.085" W (8.00mm x 2.16mm) | Termination Style | SMD/SMT |
Product Info
| Type | Low Pass | Series | 4700 |
| Values | L = 0.1µH, C = 5000pF | Technology | LC (Pi) |
| Applications | Telecommunications | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
