CST206-3A
| Manufacturer | |
| Description | Current Transformers 70mH 130A SENSING TRANSF 130MH CRNT SENSE Transformer;Current Sense;Ind 130mH;Cur 70A;PCB;DCR 12.4 Ohms Current Transformer Sensors 70mH 130A SENSING Current Transformer 1:300 12.4Ohm Prim. DCR 130000uH Prim. 70000mA Prim. 2Term. PC Pin Thru-Hole Transformer;CurrentSense;Ind130mH;Cur70A;PCB;DCR12.4Ohms |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Current Transformer Sensors | Factory Pack Quantity | 126 |
Compliance
| RoHS | RoHS Compliant | Standards | UL |
Electrical
| Frequency | 20-200kHz | Inductance | 130 mH |
| Number of Outputs | 1 | DC Resistance (DCR) | 12.4Ohms |
| Phase Noise Typ (dBc/Hz) | 1 | Current - Supply (Main IC) | 70A |
| DC Resistance (DCR) - Primary | 250μOhms(Max.) | Turns Ratio - Primary:Secondary | 1:500 |
Mechanical
| Width | 10.16 mm | Height | 31.11 mm |
| Length | 27.3 mm | Weight | 0.576000 oz |
| Termination | Thru-Hole | Mounting Style | Through Hole |
| Size / Dimension | 1.075"L×0.4"W×1.225"H | Termination Style | Radial |
Product Info
| Type | CurrentSense | Manufacturer | CSTSeries |
| Configuration | Encapsulated | Number of Turns | 300 |
Environmental
| Temperature Rating | 130°C | Operating Temperature | +40°C |
