TOF 10-24S
| Manufacturer | |
| Description | SMPSU w/screw terminal, 24Vdc 12W PSU, OPEN, 10W, 24V/0.5A |
| Category |
对参数有疑问？问 AI 助手
Compliance
| Tariff No | 85044082 | Approval Agency | :CE, UL |
Electrical
| Noise | ±1% | Frequency | :63Hz |
| Efficiency | 78% | Output Type | :Fixed |
| Power - Max | :10W | Power - Rated | 10W |
| Voltage Rating | 110 → 370 V dc, 85 → 264 V ac | Frequency - Max | :63Hz |
| Line Regulation | ±0.5% | Load Regulation | ±0.5% |
| Current - Output | 0.5A | Voltage - Supply | :47Hz |
| Number of Outputs | 1 | Power Supply Type | :Switch Mode |
| Voltage - Input (Min) | :85V to 264V | ||
Mechanical
| Depth | 20mm | Width | 50mm |
| Height | :20mm | Length | 105mm |
| Weight | 75g | Mounting Type | :Chassis |
| Package Cooled | Open Frame | ||
Product Info
| Applications | :General Purpose | ||
Environmental
| Operate Time | 250000h | Operating Temperature | -10°C |
| Maximum Temperature Limit | +60°C | ||
