TEL 5-2411
| Manufacturer | |
| Description | TEL5 DC-DC converter,18-36Vin 5V 5W CONVERTER, DC-DC, 5V, 5W TRACOPOWER TEL 5 系列 隔离式直流-直流转换器 , 5V dc输出, 1A输出 ±1%负载调节 ±0.3%线路调节 |
| Category |
对参数有疑问？问 AI 助手
Compliance
| Tariff No | 85044090 | Approval Agency | :- |
Electrical
| Noise | 75mV | Efficiency | 83% |
| Power - Max | :5W | Power - Rated | 5W |
| Converter Type | :Isolated POL | Voltage Rating | 24V dc |
| Line Regulation | ±0.3% | Load Regulation | ±1% |
| Current - Output | 1A | Number of Outputs | 1 |
| Voltage - Isolation | 1.5kV | Voltage - Input (Min) | :Fixed |
| DC Voltage - Input (Max) | :36V | ||
Mechanical
| Depth | 10.2mm | Width | 20.3mm |
| Height | :10.2mm | Length | 32mm |
| Weight | 0.012 | Mounting Type | Through Hole |
| Package / Case | DIP 24, PDIP | ||
Environmental
| Operate Time | 1000000h | Operating Temperature | -40°C |
| Maximum Temperature Limit | +85°C | ||
