TPS2375DG4
| Manufacturer | |
| Description | IEEE 802.3AF POE POWERED DEVICE CONTROLLERS Power Controller 8-Pin SOIC Tube IC CTRLR POE POWERED IEEE 8-SOIC TPS2375DG4, Ethernet Controller, 8-Pin SOIC Hot Swap Voltage Controllers IEEE 802.3af PoE Pwr Device Cntrler POE Controller 0V 57V 13W 8-Pin SOIC IEEE 802.3af PoE Powered Device Controllers |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | PoE / LAN Solutions | Product Category | Hot Swap Voltage Controllers |
| Standard Package | Rail / Tube | Factory Pack Quantity | 75 |
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | 802.3af (PoE) |
| Part Status | ACTIVE | Rad Hardened | No |
| Fault Protection | Latch | ||
Electrical
| Current | 405 | PoE Ports | Programmable |
| Power - Max | 12.95W | Power Level | 13W |
| Power - Rated | 13 W | Current - Output | 240µA |
| Voltage - Supply | 0 V ~ 57 V | Number of Channels | 1 |
| Rds On (Max) @ Id, Vgs | 580 | Current - Short Circuit (Isc) | 0.405 A |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 3.91mm | Height | 1.58mm |
| Length | 4.9mm | Weight | 0.002561 oz |
| Packaging | Tube | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 8SOIC |
| Package Cooled | SOIC | Package Quantity | 75 | TUBE |
| Size / Dimension | 4.9 x 3.91 x 1.58mm | Number of Positions | 8 |
| Supplier Device Package | 8-SOIC | ||
Product Info
| Type | Controller (PD) | Series | TPS2375 |
| Software | SLVS525B | Pattern Number | Y |
| Auxiliary Sense | No | Internal Switch(s) | Yes |
| Utilized IC / Part | View | ||
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40 to 85 °C |
| Operating Temperature - Junction | 85C | ||
Documents & Media
PDF Document
