TPS2041BDBVR
| Manufacturer | |
| Description | USB Power SW Hi Side/DIST Single 5.5V 0.75A to 1.25A 5-Pin SOT-23 T/R Power Switch ICs - USB Sgl Ch Crnt-Ltd Pwr Dist Sw IC PWR DIST SWITCH SNGL SOT23-5 IC, POWER DISTRIBUTION SWITCH Single-Channel Current-Limited Power Distribution Switch Power Switch ICs - Power Distribution Sgl Ch Crnt-Ltd Pwr Dist Sw |
| Category |
Business
| Other Names | 296-21263-2 | Product Category | Power Switch ICs - USB |
| Standard Package | Cut Tape | Factory Pack Quantity | 3000 |
| Standard Package Name | SOT-23 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85235290 |
| Part Status | ACTIVE | Rad Hardened | No |
Electrical
| Current - Test | 0.5 | Voltage Rating | :5.5V |
| Voltage - Supply | 2.7 V | Number of Outputs | 1 |
| Regulator Topology | Constant-Current | Current Rating (Max) | Catalog |
| Voltage - Input (Min) | 2.7 to 5.5 V | Rds On (Max) @ Id, Vgs | 140 mOhm |
| Power Dissipation (Max) | :285mW | Input Logic Level - High | :Active Low |
| On-State Resistance (Max) | :0.095ohm | Current - Short Circuit (Isc) | 0.75 to 1.25 A |
| Common Mode Transient Immunity (Min) | Industrial | Drive Voltage (Max Rds On, Min Rds On) | 70 |
Mechanical
| Width | 1.75(Max) | Weight | 0.002 |
| Packaging | Reel | Lead Style | Gull-wing |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :5 |
| Package / Case | 5SOT-23 | Package Cooled | SOT-23 |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 3.05(Max) |
| Package Quantity | SOT-23 | Number of Positions | 5 |
| Shell Size - Insert | 1.3(Max) | Supplier Device Package | SOT-23-5 |
Product Info
| Type | High Side Switch|USB Power Distribution Switch | DELETED | Compliant |
| Software | SLVS514L | Switch Type | :High Side |
| Programmable | Active Low | Pattern Number | Y |
| Internal Switch(s) | Yes | Number of Switches | 1 |
| Utilized IC / Part | View | Printed Circuit Board | 5 |
Environmental
| Temperature - Test | -40 to 85 | Thermal Resistance | :Yes |
| Operating Temperature | -40 to 85 °C | ||
