TLV320AIC3106IZQER
| Manufacturer | |
| Description | Audio Codec 2ADC / 2DAC 24-Bit 80-Pin BGA MICROSTAR JUNIOR T/R IC STEREO AUDIO CODEC LP 80-BGA Interface - CODECs Low-Power Stereo Low-Power Stereo CODEC with 10 Inputs, 7 Outputs, HP Amplifier and Enhanced Digital Effects |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Audio CODECs | Other Names | 296-21655-2 |
| Product Category | Interface - CODECs | Standard Package | Tape & Reel |
| Factory Pack Quantity | 2500 | Standard Package Name | BGA |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Part Status | ACTIVE | ||
Electrical
| DAC Type | 2 | Interface | Serial (2-Wire, I2C, SPI) |
| S/N Ratio | 102 | Output Fan | Yes |
| Resolution | 24 bit | Sigma Delta | Yes |
| Input Signal | L R I2S DSP TDM | Output Power | 14 mW |
| Data Interface | PCM Audio Interface | Spectral Range | -88 |
| Voltage Rating | 2.7 | Data Rate (Max) | 96 kSPs |
| Number of DAC's | 7 | Voltage - Supply | 3.3 V |
| Distortion Rating | -94 | Power Supply Type | Analog|Digital |
| Resolution (Bits) | 24 Bit | Number of Channels | 2ADC /2 DAC |
| Sampling Frequency | 96 ksps | Current Rating (Max) | Catalog |
| Number of ADCs / DACs | 6 | Voltage - Supply (Min) | 3.6 |
| Power - Average Forward | 14 | Voltage - Supply, Analog | 2.7 V ~ 3.6 V |
| Voltage - Supply, Digital | 1.65 V ~ 1.95 V | S/N Ratio, ADCs / DACs (db) Typ | 92 / 102 |
| Dynamic Range, ADCs / DACs (db) Typ | 91 / 92 | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 5.1(Max) | Height | 0.74 mm |
| Length | 5 mm | Weight | 0.001937 oz |
| Packaging | Tape and Reel | Lead Style | Ball |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 80BGA MICROSTAR JUNIOR | Length - Overall | 5.1(Max) |
| Package Quantity | BGA MICROSTAR JUNIOR | Number of Positions | 80 |
| Shell Size - Insert | 0.77(Max) | Supplier Device Package | 80-BGA MICROSTAR JUNIOR (5x5) |
Product Info
| Type | General Purpose | Series | TLV320AIC3106 |
| Features | 3D EQ Matrix Mixing PLL Alt Audio Int. HS detect | Software | SLAS509F |
| Manufacturer | Texas Instruments | Control Interface | SPI I2C |
| Functional Diagram | fbd_slas509f.gif | Utilized IC / Part | View |
| Printed Circuit Board | 80 | Number of Inputs and Type | 10 / 7 |
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40°C ~ 85°C |
