TLC5925IPWR
| Manufacturer | |
| Description | LED DRVR 3.3V/5V 24-Pin TSSOP T/R LED Lighting Drivers Lo-Pwr 16Ch Constant Crnt LED Sink Drvr IC LED DRIVER LINEAR 24-TSSOP IC, LED SINK DRIVER, 16CH, 24TSSOP IC, LED DRIVER, CONSTANT CURRENT TSSOP24 Low-Power 16-Channel Constant-Current LED Sink Driver LED 驱动器, 3.3 V、5 V, 24引脚 TSSOP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 296-24466-2 | Product Category | LED Lighting Drivers |
| Standard Package | Tape & Reel | Factory Pack Quantity | 2000 |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Part Status | ACTIVE | Rad Hardened | No |
Electrical
| Dimming | :Analogue | Frequency | 30MHz |
| Display Type | :LED | Input Signal | Serial |
| Power - Rated | 1.1 W | Voltage Rating | 3 V to 5.5 V |
| Data Rate (Max) | 30 | Current - Output | 13000 mA |
| Current - Supply | 13 mA | Voltage - Supply | 3 to 5.5 V |
| Number of Outputs | 16 | LED Forward Voltage | 17 |
| Current Rating (Max) | Catalog | Frequency - Switching | :30MHz |
| Voltage - Input (Min) | 17V | Voltage - Supply (Min) | 3 V |
| Power Dissipation (Max) | 1100 mW | Current - Output / Channel | 45 |
| Current - Output High, Low | -1000(Min) uA | Constant Current Load - Max | Yes |
| Channel-to-Channel Matching (DeltaRon) | 4 | Voltage - Continuous Operating (Max) (MCOV) | :5.5V |
Mechanical
| Width | 4.5(Max) | Weight | 0.003157 oz |
| Packaging | Reel | Case Color | :TSSOP |
| Lead Style | Gull-wing | Termination | :SMD |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :24 | Package / Case | 24TSSOP |
| Package Cooled | TSSOP | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 7.9(Max) | Package Quantity | TSSOP |
| Number of Positions | 24 | Shell Size - Insert | 1.05(Max) |
| Supplier Device Package | 24-TSSOP | ||
Product Info
| Type | LED Lighting Display, Signage, Automotive | Series | TLC5925 |
| DELETED | Compliant | Features | Thermal Shutdown |
| Software | SLVS765A | Topology | Linear, High Side |
| Base Unit | :5925 | Control Interface | :Serial |
| Utilized IC / Part | View | Internal Connection | Yes |
| Channels per Circuit | 16 | Application Specifics | :Display, Lighting |
| Printed Circuit Board | 24 | ||
Environmental
| Temperature - Test | -40 to 125 | Operating Temperature | + 85 C |
| Operating Temperature - Junction | 85C | ||
