SN74LVC1G86DBVR
| Manufacturer | |
| Description | XOR Gate 1-Element 2-IN CMOS 5-Pin SOT-23 T/R IC EX-OR GATE 2-IN SOT-23-5 Logic Gates 2 Input IC, EX-OR, SINGLE 2-INPUT, SMD Single 2-Input Exclusive-OR Gate |
| Category |
Business
| Product | XOR | Other Names | 296-9853-2 |
| Product Category | Logic Gates | Standard Package | Cut Tape, Tape & Reel |
| Factory Pack Quantity | 3000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423990 | Part Status | ACTIVE |
| Rad Hardened | No | ||
Electrical
| Voltage | 1.8 2.5 3.3 5 | Input Type | CMOS/TTL |
| Logic Type | XOR (Exclusive OR) | Output Type | CMOS |
| Number of Bits | 1 | Voltage Rating | 1.65 V |
| Current - Output | :32mA | Number of Inputs | 2 |
| Voltage - Supply | 1.65 V ~ 5.5 V | Number of Outputs | 1 |
| Number of Elements | 1 | Current Rating (Max) | Catalog |
| Frequency - Output 1 | 150 | Voltage - Supply (Min) | 5.5 V |
| Current - Quiescent (Iq) | 10 uA | Delay Time - Propagation | 5 ns |
| Logic Voltage - VIL, VIH | 1.7 V ~ 2 V | Current - Quiescent (Max) | 10µA |
| Current - Output High, Low | 32mA, 32mA | Current - Output Source/Sink | 32/-32 |
| Max Propagation Delay @ V, Max CL | 5@3.3V|4@5V ns | Propagation Delay tpLH / tpHL (Max) | 9.9 5.5 5 4 |
Mechanical
| Weight | 0.000557 oz | Packaging | Tape & Reel (TR) |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :5 |
| Package / Case | 5SOT-23 | Package Cooled | SOT-23 |
| Material Finish | :MSL 1 - Unlimited | Package Quantity | 3000 | LARGE T&R |
| Number of Positions | 5 | Supplier Device Package | SOT-23-5 |
Product Info
| Series | SN74LVC1G86 | Function | XOR |
| Software | SCES222O | Base Unit | :74 |
| Technology | CMOS | Number of Gates | 1 |
| Number of Circuits | 1 | RF Family/Standard | LVC |
| Utilized IC / Part | View | Number of Inputs and Type | 0 |
Environmental
| Temperature - Test | -40 to 125 | Operating Temperature | -40 to 85 °C |
Documents & Media
