PCF8575PWE4
| Manufacturer | |
| Description | PCF8575DBQ/R, DGVR, DW/R, PW/R Interface - I/O Expanders Remote 16-Bit I2C & SMBus I/O Expander IC I/O EXPANDER I2C 16B 24TSSOP PCF8575PWE4 IC, 16BIT I2C/SMBUS EXPANDER, 8575 Remote 16-Bit I2C and SMBus I/O Expander with Interrupt Output |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Interface - I/O Expanders | Standard Package | 60 |
| Factory Pack Quantity | 60 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423990 | Part Status | :8575 |
Electrical
| Frequency | :400kHz | Interface | I²C, SMBus |
| Logic Type | PCF8575 | Output Type | Push-Pull |
| Number of I/O | 16 | Number of Bits | :16 |
| Clock Frequency | 400kHz | Frequency - Max | 400 kHz |
| Current - Output | :10µA | Interrupt Output | Yes |
| Voltage - Supply | 2.5 V to 5.5 V | Sampling Frequency | 0.4 |
| Current Rating (Max) | Catalog | Current - Output Source/Sink | 1mA, 25mA |
Mechanical
| Weight | 0.003157 oz | Packaging | Tube |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :24 |
| Package / Case | TSSOP-24 | Material Finish | :MSL 1 - Unlimited |
| Package Quantity | 60 | TUBE | Number of Positions | :8575 |
| Supplier Device Package | 24-TSSOP | ||
Product Info
| Series | PCF8575 | Features | POR |
| Software | SCPS121F | Base Unit | :8575 |
| Communications | :I/O Expander | Control Interface | :I2C, Parallel |
| Utilized IC / Part | View | Other Specifications | :16bit |
| Number of Inputs and Type | 16 | ||
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | - 40 C to + 85 C |
Documents & Media
PDF Document
