PCF8575CDWE4
| Manufacturer | |
| Description | PCF8575CDBQ/R, DGVR, DW/R, PW/R IC I/O EXPANDER I2C 16B 24SOIC Interface - I/O Expanders Remote 16-Bit I2C & SMBus I/O Expander PCF8575CDWE4 IC, 16BIT I2C/SMBUS EXPANDER, 8575 Interface; I/O expander; I2C, parallel; Channels:1; 4.5÷5.5VDC Remote 16-Bit I2C and SMBus I/O Expander with Interrupt Output |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Interface - I/O Expanders | Standard Package | 25 |
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85411000 | Part Status | :8575 |
Electrical
| Frequency | :400kHz | Interface | I²C, SMBus |
| Logic Type | PCF8575C | Output Type | Open Drain |
| Number of I/O | 16 | Number of Bits | :16 |
| Clock Frequency | 400kHz | Frequency - Max | 400 kHz |
| Current - Output | :10µA | Interrupt Output | Yes |
| Voltage - Supply | 4.5 V ~ 5.5 V | Number of Channels | 1 |
| Sampling Frequency | 0.4 | Current Rating (Max) | Catalog |
| Current - Output Source/Sink | 10mA, 25mA | ||
Mechanical
| Weight | 0.022025 oz | Packaging | Tube |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :24 |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) | Material Finish | :MSL 1 - Unlimited |
| Package Quantity | 15 | Number of Positions | :8575 |
| Supplier Device Package | 24-SOIC | ||
Product Info
| Spg | 15 | Type | interface |
| Series | PCF8575C | Features | POR |
| Software | SCPS123F | Base Unit | :8575 |
| Communications | :I/O Expander | Number of Units | 1 |
| Control Interface | :I2C, Parallel | Functional Diagram | alt_scps123f.gif |
| Utilized IC / Part | I/O expander | Other Specifications | :16bit |
| Number of Inputs and Type | 16 | ||
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40°C ~ 85°C |
